10.1" · INDUSTRIAL MONITOR · PANEL MOUNT

Industrial Panel Mount Displays for Embedded Installations

Panel mount monitors are selected when front-side installation, mechanical alignment, and sealed integration are required. These displays are designed to be installed through a cutout in the equipment panel, secured from the rear, and aligned flush with the enclosure surface. They are commonly used in control cabinets, industrial machinery, and HMI systems where stability, protection, and long-term availability matter.

Factory Direct OEM / ODM Ready Fast Quotation
10.1"Промышленный мониторPanel Mount

Browse available 7” industrial monitor models below. For OEM/ODM projects, include interface, brightness, touch type and operating environment in the comments to receive a faster quotation.

  • Screen size: 7 inch (industrial LCD)
  • Application: industrial equipment, automation systems
  • Installation: panel mount / open frame / VESA (optional)
  • Project type: standard models and OEM customization
Integration

I/O & mechanical options

Interface and mounting choices to match your enclosure and system design.

Industrial

Stable long-term supply

Program continuity with controlled specs for long-term operation.

Support

Engineer response

Faster clarification for OEM details and application constraints.

Available 7" industrial monitor Models

Select a model and click Enquire Now to send requirements. We will reply with availability and quotation.

panel mount touch monitor

ETH070TCIPA02

7" Panel Mount Touch Monitor

Промышленный монитор Panel Mount
  • Size: 7"
  • Resolution: 1024*600
  • Brightness: 1000nits
  • Touch screen: Pcap Touch Screen
  • Interface: VGA+HDMI
  • Working temperature: -20 to 70 degree
  • IP degree: IP65 front waterproof
  • Power supply: 12VDC
  • Mounting type: Panel Mount
open frame monitor

ETH070TCOPA01

7"outdoor Open frame Monitor

Промышленный монитор Open Frame
  • Size: 7"
  • Resolution: 800*480
  • Brightness: 700nits
  • Touch Screen: Pcap touch screen
  • Interface: VGA+HDMI
  • Operating Temperature: -30°C to 85°C
  • IP Degree: Front Panel IP65
  • Mounting Options: Open Frame Mount
PANEL MOUNT TOUCH MONITOR

ETH101TCIPA01

10.1" Panel Mount Industrial Monitor

Промышленный монитор Panel Mount
  • Size: 10.1"
  • Resolution: 1280*800
  • Brightness: 1000nits
  • Touch Screen: PCAP Touch Screen
  • Interface: VGA+HDMI
  • Working Temperature: -20°C to 70°C
  • Front Frame: IP65 front Waterproof, Aluminum Frame
  • Mounting Type: Panel Mount
  • Customization: Support 350nits, and Customization per requirement
outdoor touch monitor

ETH101TCOPA03-6

10.1" Outdoor Industrial Open Frame Monitor

Промышленный монитор Open Frame
  • Size: 10.1"
  • Resolution: 1280*800
  • Brightness: 1000nits
  • Touch Screen: PCAP touch ,support waterdrop touch. Anti UV.
  • Vandal proof: 6mm thickness Cover glass, IK10 Protection
  • Bonding Type: Optical Bonding
  • Interface: VGA+HDMI
  • Working temperature: -20°C to 70°C
  • IP Degree: IP65 front waterproof ,with waterproof gasket
  • Mounting Type: Open Frame Mount
panel mount touch monitor

ETH121TCIPA00

12.1" Panel Mount industrial Monitor

Промышленный монитор Panel Mount VESA
  • Size: 12.1"
  • Resolution: 1024*768
  • Brightness: 1000nits
  • Touch screen: projected capacitive touch screen
  • Inerface: VGA+HDMI
  • Working temperature: -20 to 70 degree
  • Mounting Type: Panel Mount
  • IP degree: Front IP65
PANEL MOUNT TOUCH MONITOR

ETH121TROMA01

12.1" Resistive Touch Monitor

Промышленный монитор Panel Mount VESA
  • Size: 12.1"
  • Resolution: 1280*800
  • Brightness: 1000nits
  • Touch Screen: 5 wire resistive touch screen
  • Interface: VGA+HDMI
  • Working Temperature: -20 to 70 degree
  • Mounting Type: Panel Mount
  • IP degree: Front panel IP65
PANEL MOUNT TOUCH MONITOR

ETH150TCIPA00

15" Panel Mount Touch monitor

Промышленный монитор Panel Mount VESA
  • Size: 15"
  • Resolution: 1024*768
  • Brightness: 1000nits brightness (support 350nits )
  • Touch Screen: Pcap Touch screen, suspport waterdrop touch
  • Interface: VGA+HDMI
  • Working temperature: -20 to 70 degree
  • IP Protection: IP65 Front waterproof
  • Mounting Type: Panel Mount
7" open frame touch monitor ETT070H701

ETT070H701

7” Open Frame Display

Промышленный монитор Open Frame
  • Size: 7"
  • Resolution: 1024*600
  • brightness: 700nits
  • Interface: VGA+HDMI
  • Power supply: 12V3A
  • working temperature: -20 to 70 degree
  • Mounting type: Open frame
open frame monitor

ETT070TCOPA00

7" Open Frame Touch Monitor

Промышленный монитор Open Frame
  • Size: 7"
  • Resolution: 1024*600
  • Brightness: 250nits
  • Touch Screen: Pcap ,10 Point touch
  • Interface: VGA+HDMI
  • Working temperature: -20 to 70 degree
  • Mounting Options: Open Frame Mount
flush mount touch monitor

ETT101CIMB01

10.1" Flush Mount Industrial Monitor

Промышленный монитор Open Frame
  • Size: 10.1"
  • Resolution: 1280*800
  • Brightness: 350nits
  • Touch Screen: Pcap Touch screen
  • Interface: VGA+HDMI
  • Working Temperature: -20°C to 70°C
  • Mounting Type: Flush Mount
industrial montor

ETT101OP003

10.1" Open frame Touch monitor

Промышленный монитор Open Frame
  • Size: 10.1"
  • Resolution: 1280*800
  • Brightness: 350nits
  • Touch Screen: PCAP touch screen, 10 point touch
  • Interface: VGA+HDMI
  • Working temperature: -20 to 70 degree
  • Mounting: Open frame
  • Support: OEM/ODM
metal frame industrial Monitor

ETT101TCFPC01-6

10.1" Metal Frame Industrial Touch Monitor

Промышленный монитор Open Frame
  • Size: 10.1"
  • Resolution: 1280*800
  • Brightness: 350nits
  • Touch Screen: Pcap Touch Screen
  • Glass Thickness: 6mm thickness, suitable for public use
  • Interface: VGA+HDMI
  • Power Supply`: 12V3A
  • Working Temperature: -20°C to 70°C
  • Mounting Type: Vesa And Open Frame Mount
panel mount touch monitor

ETT104TCIPA00

10.4" Panel Mount Touch Monitor

Промышленный монитор Panel Mount
  • Size: 10.4"
  • Resolution: 1024*768
  • Brightness: 500nits
  • Touch Screen: Pcap Touch Screen
  • Interface: VGA+HDMI
  • Working temperature: -20 to 70 degrees
  • Power supply: 12V DC
  • Mounting Type: Panel Mount
  • Option: Support 1000nits for outdoor use
open frame touch monitor

ETT104TCOPP01

10.4" Open Frame Touch Monitor

Промышленный монитор Open Frame
  • Size: 10.1"
  • Resolution: 1024*768
  • Brightneess: 500nits
  • Touch Screen: PCAP touch Screen
  • Interace: VGA+DVI+HDMI
  • Working Temperature: -20 to 70 degree
  • Mounting Type: Open Frame Mount
  • Option: Support 1000nits for outdoor application
industrial montor

ETT121TCOPA01

12.1” Open Frame Industrial Monitor

Промышленный монитор Open Frame VESA
  • Size: 12.1"
  • Resolution: 1280*800
  • Brightness: 500nits
  • Touch Screen: Pcap Touch screen
  • Interface: VGA+HDMI
  • Working temperature: -20 to 70 degree
  • Mounting type: Open Frame
  • Customization: provide customization service per requirement
Metal frame touch monitor

ETT150TCFPC02-6

15" Metal Frame Touch Monitor

Промышленный монитор Open Frame VESA
  • Size: 15"
  • Resolution: 1024*768
  • Brightness: 350nits
  • Touch Screen: PCAP touch screen, 6mm thickness cover glass, Vandal proof
  • Interface: VGA+HDMI
  • Mounting Type: VESA and embedded Mount
open frame monitor

ETT150TCOPA00

15" Open Frame Touch Monitor

Промышленный монитор Open Frame VESA
  • Size: 15"
  • Resolution: 1024*768
  • Brightness: 350nits
  • Touch Screen: Pcap Touch screen, support 10 point touch
  • Interface: VGA+HDMI
  • Working Temperature: -20 to 70 degree
  • Mounting type: Open frame Mount
  • OEM/ODM: Support 1000nits brightness for outdoor use
open frame monitor

ETT150TCOPA02

15" Open Frame Touch Monitor

Промышленный монитор Open Frame VESA
  • Size: 15"
  • Resolution: 1024*768
  • Brightness: 350nits
  • Viewing angle: 88/88/88/88
  • Touch Screen: PCAP touch screen
  • Interface: VGA+HDMI+DP
  • Power supply: DC12V 3A, aviation connector for power input
  • Mounting type: VESA Mount, Embedded Mount
open frame touch monitor

ETT150TCOPN03

15" Open Frame touch Monitor

Промышленный монитор Open Frame
  • Size: 15"
  • Resolution: 1024*768
  • Brightness: 350nits
  • Touch Screen: Pcap Touch Screen
  • Interface: VGA+HDMI
  • Working temperature: -20 to 70degree
  • Mounting type: Open frame, Embedded
To recommend the right model, please include:
Application • Environment • Brightness • Touch type • Interface/platform • Operating temperature
КОНТАКТ

Готовы к инженерной экспертизе?

Расскажите о своей заявке и основных требованиях к Сенсорные мониторы или Панельные ПК. Наши инженеры проанализируют целесообразность, риски и порекомендуют правильное направление конфигурации.

Лучше всего подходит для OEM/ODM и интеграционных проектов. Обычно ответ на запрос поступает в течение 1 рабочего дня (GMT+8).
Для RFQ, пожалуйста, укажите размер/яркость, список интерфейсов, монтаж, рабочую температуру и целевую дату поставки (если срочно).
